Krachpedale

LV2 pedals for the MOD Dwarf

A small set of odd effects and a synth, written from scratch for the MOD Dwarf. Pick a pedal, check the checksum, put it on your Dwarf.

Pedals

Shipahoy pedal face

Shipahoy

Resonant filter that hops on every tempo step, steered by Lua scripts.

Version 0.3.0

Size and SHA-256
Size
719 kB (735786 bytes)
SHA-256
a9c70e4abd3295ca8ae6f7182f632687d6566ea22f5a0f63f1eb259549956156
Download
Eigenghost pedal face

Eigenghost

Diffused 16-line reverb with two pitch-shifting lines for shimmer tails.

Version 0.1.1

Size and SHA-256
Size
490 kB (501628 bytes)
SHA-256
e04d7a511e757801ba023b2406b705be347f898899c41669b6ec51d46b41da7f
Download
Jays Twin pedal face

Jays Twin

A simple Fender Twin Reverb: tone stack, drive and 2x12 cabinet. Gain goes to eleven.

Version 0.1.0

Size and SHA-256
Size
507 kB (519347 bytes)
SHA-256
4bc140180453e5ca7305d7252c83a3e5840258a9213dddbe56a7cdde61d7363c
Download
Dissanova pedal face

Dissanova

Ring modulator whose carrier is steered by Lua scripts.

Version 0.1.0

Size and SHA-256
Size
748 kB (765867 bytes)
SHA-256
b8c318d7c0c586a84abf62a9fc390fd162a25bf13a87d795f12bd7354f5aeab0
Download
Morphexsynth pedal face

Morphexsynth

MPE subtractive synth, 12 voices, Lua patches, with phaser, chorus and reverb.

Version 0.1.1

Size and SHA-256
Size
824 kB (843811 bytes)
SHA-256
c3411c2b8516be9b15b7e3befeb3739f89c9d08ff2928259dae89523f47b5495
Download

The bundles are built for the MOD Dwarf (aarch64). They do not run on a computer.

Install on the Dwarf

  1. Download the zip of a pedal and unpack it. You get a folder named jaypacks-<name>.lv2.
  2. With the Dwarf connected over USB, open a terminal (macOS or Linux) in the folder that holds the unpacked pedal and send it to the Dwarf. Replace shipahoy with the pedal you downloaded:
    tar -czf - jaypacks-shipahoy.lv2 | base64 | curl -F "package=@-;filename=package" http://192.168.51.1/sdk/install
    The answer ends with "ok": true. To update a pedal, take it out of the loaded pedalboard first: the Dwarf refuses to replace a pedal that is in use.
  3. Open the Dwarf's web interface and look for the pedal by its name in the plugin list.
